NEO Messtechnik GIA Series Grid Impedance Analyzer
NEO Messtechnik GIA Series Grid Impedance Analyzer
The Neo Messtechnik Grid Impedance Analyzers GIA1 and GIA3 allows measuring single-phase grid impedance or three-phase (phase to ground or phase to phase) in a frequency range up to 450 kHz. The NEO GIA series is powered by the Neo Messtechnik PQA8000H instrument.
Regular price
$22,250.00 AUD
Regular price
$14,700.00 AUD
Sale price
$22,250.00 AUD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
 |  |  |  | |
|---|---|---|---|---|
| General | ||||
Brand |
NEO MESSTECHNIK
|
NEO MESSTECHNIK
|
NEO MESSTECHNIK
|
NEO MESSTECHNIK
|
SKU |
GIA1-150
|
GIA1-450
|
GIA3-150
|
GIA3-450
|
Price |
$22,250.00
|
$24,000.00
|
$27,715.00
|
$29,165.00
|
| Data Acquisition | ||||
SNR Signal-to-Noise-Ratio
|
>100 dB
|
>100 dB
|
>100 dB
|
>100 dB
|
| Voltage Inputs | ||||
Input Range Measurement Range
|
230 V, 400 V, and 690 V (Optional)
|
230 V, 400 V, and 690 V (Optional)
|
230 V, 400 V, and 690 V (Optional)
|
230 V, 400 V, and 690 V (Optional)
|
Safety |
CAT IV 300V and CAT IV 600V (Optional)
|
CAT IV 300V and CAT IV 600V (Optional)
|
CAT IV 300V and CAT IV 600V (Optional)
|
CAT IV 300V and CAT IV 600V (Optional)
|
| Current Inputs | ||||
Max Current |
5 A
|
5 A
|
5 A
|
5 A
|
| Measurement | ||||
Time |
400 ms per Excitation
|
400 ms per Excitation
|
400 ms per Excitation
|
400 ms per Excitation
|
Wiring |
Line to Neutral (L-N) and Line to Line (L-L)
|
Line to Neutral (L-N) and Line to Line (L-L)
|
Line to Neutral (L-N) and Line to Line (L-L)
|
Line to Neutral (L-N) and Line to Line (L-L)
|
Type |
Single-Phase
|
Single-Phase
|
Three-Phase
|
Three-Phase
|
| Physical | ||||
Weight |
2.0 kg
|
2.0 kg
|
2.0 kg
|
2.0 kg
|
| Frequency | ||||
Range |
Up to 150 kHz
|
Up to 450 kHz
|
Up to 150 kHz
|
Up to 450 kHz
|
Nominal |
50 Hz, 60 Hz, and 16.7 Hz
|
50 Hz, 60 Hz, and 16.7 Hz
|
50 Hz, 60 Hz, and 16.7 Hz
|
50 Hz, 60 Hz, and 16.7 Hz
|
| Data | ||||
Export Formats |
CSV, RAW, and JPEG
|
CSV, RAW, and JPEG
|
CSV, RAW, and JPEG
|
CSV, RAW, and JPEG
|
| In the Box | ||||
Supplied |
GIA1-150, Connection Cable to Neo Messtechnik PQ8000H Series, and NEO GIA Software
|
GIA1-450, Connection Cable to Neo Messtechnik PQ8000H Series, and NEO GIA Software
|
GIA3-150, Connection Cable to Neo Messtechnik PQ8000H Series, and NEO GIA Software
|
GIA3-450, Connection Cable to Neo Messtechnik PQ8000H Series, and NEO GIA Software
|
